Inline food printer
FLEXPRINT IL-700
Print directly onto food in continuous production with an 18-inch conveyor, automatic alignment, and image masking for irregular shapes. The IL-700 uses food-grade ink and supports a second print module for pre- or post-coating.
- Maximum throughput
- Up to 120 items/minute
- Conveyor width
- 18 inches
- Duty cycle
- Continuous
Throughput based on 2.5 × 2.5-inch items. See full specifications
Continuous printing with automatic alignment
Automatic alignment and image masking accommodate product orientation and irregular shapes. A 24-inch touchscreen provides access to print controls.
The printer separates from the conveyor for cleaning. For applications that need pre- or post-coating, the system supports a second print module.
IL-700 specifications
Dimensions and weight are approximate.
- Maximum throughput
- Up to 120 items/minute (based on 2.5 × 2.5-inch items)
- Approximate dimensions
- 10 ft (L) × 5 ft (W) × 6 ft (H)
- Approximate weight
- 1,200 lb
- Conveyor width
- 18 inches
- Duty cycle
- Continuous
- Maximum digital print width
- 4.426 inches
- Belt material
- Food grade
- Printhead type
- Piezo
- Print colors
- CMYK
- Registration system
- Precision linear measurement device (60 rasters/inch)
- Power requirements
- 120 VAC, 20 A
- Ink system
- Fully enclosed cabinet
- Automatic product height detection
- Yes
- Selectable image scaling
- Yes
- Image masking for irregular shapes
- Yes
- Rotational data / automatic alignment
- Yes
- Second print module for pre- or post-coating
- Supported
- Automatic real-time ink calculation
- Yes
- Operator touchscreen
- 24 inches on swing arm
- Printer separates from conveyor for cleaning
- Yes
- Controller software
- Windows downloads and updates
